LDF1RK-50 Cable Heliax Corrugado de Cobre 1/4 de Pulgada Retardante Al Fuego
LDF1RK-50
ANDREW
$ 164.00
$ 164.00
El precio incluye IVA
Descripción del producto
LDF1RK-50 Cable Heliax Corrugado de Cobre 1/4 de Pulgada Retardante Al Fuego
Electrical Specifications
| Cable Impedance | 50 ohm ±1 ohm |
| Capacitance | 77 pF/m | 23.47 pF/ft |
| dc Resistance, Inner Conductor | 5.151 ohms/km | 1.57 ohms/kft |
| dc Resistance, Outer Conductor | 4.003 ohms/km | 1.22 ohms/kft |
| dc Test Voltage | 2200 V |
| Inductance | 0.059 µH/m | 0.018 µH/ft |
| Insulation Resistance | 100000 MOhms-km |
| Jacket Spark Test Voltage (rms) | 5000 V |
| Operating Frequency Band | 1 – 15800 MHz |
| Peak Power | 12.1 kW |
